Basic Info.

Gas	Air
Frequency	50-60Hz
Installation	Floor Mounted
Type	High Pressure Discharge Type
Usage	Swimming Pool/SPA Water Treatment
Warranty	1 Year
Ozone Capacity	100g/H
Application	Agriculture, Industry, Aquaculture
Power Supply	220V/50Hz or 380V/50Hz
Life Span	>10 Years
Material	304/316L Stainless Steel
Transport Package	Plywood Pallet
Specification	200g
Trademark	PIONEEREP
Origin	China
HS Code	8543709990
Production Capacity	1000 Units /Month

Product Description

Ozone Generator System for Swimming Pool
Ozone Technology: a compact ozone system
The compact ozone range is designed for disinfection of private and hotel sized swimming pools. Ozone provides effective treatment against chlorine resistant micro-organisms and significantly improves water clarity.
PSOZON series is a high-performance ozone generator system for swimming pools. The utility model has the advantages of ingenious structure, convenient installation, simple operation, high safety and low demand for cooling water. There are many advantages, such as new technology, high performance and so on. Complete set of equipment, opening the machine can run.
Specification

Model	Ozone production	Cooling water flow	Power consumption	Interface diameter		Dimension(mm)
Model	g/h	m³/h	Kwh	cooling water	ozone output	W D H
PSOZN-10	10	0.03	0.4	R1/2"	R1/2"	4000x300x1000
PSOZN-20	20	0.05	0.5	R1/2"	R1/2"	600x450x1400
PSOZN-40	40	0.08	0.9	R1/2"	R1/2"	600x450x1400
PSOZN-80	80	0.15	1.2	R1/2"	R1/2"	800x600x1700
PSOZN-120	120	0.20	2.2	R1/2"	R1/2"	1200x600x1700
PSOZN-150	150	0.30	2.6	R1/2"	R1/2"	1200x600x1700
PSOZN-200	200	0.40	3.5	R1/2"	R1/2"	1600x600x1700
PSOZN-250	250	0.50	4.0	R1/2"	R1/2"	1600x800x2000
PSOZN-300	300	0.60	5.0	R1/2"	R1/2"	1600x800x2000
PSOZN-400	400	0.80	7.0	R1/2"	R1/2"	1800x800x2000
PSOZN-500	500	1.00	8.0	R1/2"	R1/2"	1800x800x2000

Note:
1. Power consumption is based on different ozone concentration and cooling water conditions.
2. Customerize for higher ozone concentration ozone generator.

200-300g Swimming Pool Ozone Generator System with Advanced Ozone Technology

Ozone Knowledge
For a long time, in medical and health, pharmaceutical, food processing and other aspects, disinfection and sterilization of water and air has been used ultraviolet radiation, chemical fumigation, spraying and other methods, there are many defects in the use. The emergence of ozone sterilization and disinfection products provides a fast, efficient, safe and reliable disinfection method, which is the ideal substitute for traditional disinfection equipment and will inevitably be widely used.Ozone O3 is the oxygen O2 isomorphism, the composition element is the same, the composition form is different, the property is very different.Ozone is gaseous at room temperature, colorless and grassy at low concentration, and soluble in water. It is known as one of the strongest oxidants. The chemical properties of ozone are more active and have strong oxidation ability. When met with bacteria and harmful chemicals (such as formaldehyde, benzene, ammonia), immediately produce oxidation reaction, so as to play the function of sterilization and disinfection, mildew, taste, decomposition of harmful gases and so on. Ozone is unstable, and its aerobic O2 changes, reducing it to O2, within a few minutes, so it is free of pollution and residue. It is so far the world recognized that food and beverage direct disinfection of the only substance!The high concentration ozone generator produced by our company is a kind of high concentration ozone generator equipment dedicated to air purification and water treatment. It adopts the latest ozone generating device and many kinds of protection function circuits inside, and has excellent performance and extremely long working life.
Our Products advantage

All in one equipment, easy to operate
Over temperature protection, over-current protection, and over-voltage abnormality monitoring.
Ozone leakage alarm, operation fault alarm monitoring
Supply full set of auxiliary equipment, including air compressor, gas storage tank, filter, freezing dryer, adsorption dryer etc.
Use special stainless steel tube for discharge chamber
With SIEMENS PLC touch screen automatic control system, users can achieve monitoring, control, switching, setting, report, alarm, cycle start-up, emergency shutdown etc. functions.

Advantage 1. Strong sterilization and fast speed. Ozone kills Escherichia coli, hundreds of times faster than chlorine, and has an effective killing effect on viruses and bacteria in prokaryotes.
Advantage 2. Swimming pool ozone generator can prevent the accumulation of organic dirt, can improve water quality, remove color, kill pathogenic microorganisms, and the treated water can effectively prevent the spread of infectious diseases.
Advantage 3. Swimming pool ozone generator can effectively reduce pollutants in the water, reduce the formation of by-products (monochloramine, dichloramine, trichloramine, chloroform, etc.) after the chlorination of organic pollutants and protect swimmers healthy.
Advantage 4. During the treatment process, the residual ozone in the water returning to the swimming pool will not exceed the safety limit, and the air can be sterilized and purified to make the indoor air fresh and comfortable.

200-300g Swimming Pool Ozone Generator System with Advanced Ozone Technology

Field installation

Why Choose Us?1. EXPERIENCE :11 years focus on ozone generator R&D and manufacture,service of more than 1000 customers.2. 30000 square meter factory area3. Core patent technology and authorized certifications4. Strict quality control to ensure safe and reliable products5.Service: 24 hours online service,life-long maintenance6.Professional overseas sales team, supply prompt response
FAQ

1. Are you trading company or manufacturer?
We are manufacturer and trader.
2. How long is your delivery time?
Generally it's 5 days if the goods are available. It would be 20-30 days based on ozone application and capacity requirements.We could supply ODM and OEM, design layout based on actual working condition.
3. Do you provide samples?
Yes, we could offer the sample. After receiving 100% payment, we will deliver the sample to you as soon as possible.
4. What is your term of payment?
30% T/T in advance, balance before shippment.
5. How do you control quality?
The company strictly implements the ISO9001 quality management system, has passed ISO14001, ISO18001 management system certification and SGS. In addition, we have more than 20 patents technology to ensure stable and reliable product quality.
6. Does your product have any warranty?
Yes, we offer 12 months warranty from the date of the customer's confirmation.Beyond the warranty, we will also supply life-long maintenance but we will charge maintenance fee.

Contact us NOW for your needs! Holly Huang Mobil: 86-13310673079
